| weighing module structure: | |
|---|---|
| for Capacity: | |
| For platform size: | |
| for Load Cell: | |
| Weight indicator: | |
| Quantity: | |
FSG
80t Capacity Digital Weighbridge,3*18m Digital Truck Scale
* This Weighbridges are used for legal-for-trade freight weighing of road vehicles or for loading goods on the scales.
(e.g. Bulk cargo)
* Examples of some typical applications are: inbound / outbound weighing in manufacturing plants & transport
companies, or comfortable material-flow management systems, e.g. in waste management facilities.
* The combination of weighing indicators or PC solutions produces user-friendly, high-performance scale systems,
which can be easily connected to ERP-systems.
* Truck scales are pit mounted (embedded in the roadway), or above-ground scales.
Weighbridge Features:
- Width*length:3*18m(3*12m/3*24m are available)
- Material：steel
- Structure: Standard U shape beam,modules design for easy loading in truck or container
- Top Steel Thickness: 10mm checker Plate
- U Beam Height: 355mm
- U Beam thickness: (5mm/6mm/5mm)x2
- Painting: Anti rust and anti-corrosion painting
- Capacity: 80T(60t~120t upon the request)
- Weight: about 9000kg for 3*18m(6 sections)
- Foundation：Shallow / No Foundation Pit
Weighing Indicator
- Brand and model: YAOHUA DS8(digital indicator)
- Keyboard: Number keys(0~9); Function keys(24,10 composite keys with number keys)
- Max. connection number of load cell: ≤16 digital load cells
- Loadcell connection mode: 6 wire, auto compensation for long distance
- Clock: displaying year,month,date,hour,minute,second,leap year/month automatically,without the influence from power break down
- Transimission: RS 232 / RS422(optional)
- Transimission distance: ≤30 meters
- Transimission method: RS232/RS422(optional)/RS485(optional)
- Baund rate: 600/1200/2400/4800/9600(optional)
- Transmission distance: RS232:≤30 meters; RS422/RS485:≤1200 meters
- With printing interface for connecting with EPSON LQ-300(+),Panasonic KX-P1131 and KX-P121 etc. wide line printers
- Data storage:1000 truck records consisting of truck ID & corresponding tare weight 201cargo ID.1001 weighting records
- Power supply:AC 100~264V;50~60Hz DC 12V/7Ah External battery rechargeable
Load Cell:
- Brand: ZEMIC ditital load cells
- Nickel plated alloy steel IP68 sheam beam loadcell
- Accuracy class: OIML R60 C3
- Capacity: 10t~50t
- Working temperature: -35°C ~ +65°C; Storage temperature: -40°C ~ -70°C
- Safe overload: 150%FS; Ultimate overload: 300%FS
Junction Box:
- Stainless steel housing
- Working temperature: -30°C ~ +60°C
