C12 Stainless Steel Weighing Indicator with Label Barcode Printer, WIFI Label Printing Weight Indicator

C12 Stainless Steel Weighing Indicator with Label Barcode Printer

-- WIFI Label Printing Weight Indicator

    TCP/IP weighing indicator, with WiFi - WAN/LAN
    Modbus ASCII communication protocol, unidirectional and bidirectional communication are optional

Features:

• A304 Stainless steel housing weight indicator

• This weight indicator can be applied in platform scales

• With mini label barcode printer


• Maximum number of load cells: 4 x 350 Ω load cells or 8 x 700 Ω load cells

• Display: 6-bit Display, 0.8 inches LED

• High Resolution (× 10) display

• Weight unit in kg / lb

• Weighing modes: Gross and net weight weighing

• Manual and automatic weight accumulation

• Serial interface RS232 interface with continuous ASCII data output

• Baud rate 1200, 2400, 4800, 9600

• Optional RS485 interface

• Programmable zero tracking

• Programmable digital filter

• Animal weighing

• Hold function

• Counting function

• The network cable to connect the computer network interface with the LAN interface on the WiFi board.


Specifications:
